NEWCOBOND® has good shape plasticity. The board itself has a certain degree of toughness and can be bent and cut within a reasonable range. It can adapt to complex architectural shapes such as curved walls and special-shaped ceilings. It does not require complicated customized molds, reducing the construction cost of special shapes. NEWCOBOND® high-quality aluminum composite panels have a smooth surface with good gloss and weather resistance. They are not easy to fade or lose luster after long-term use. They can keep the appearance of the building clean and beautiful. They are especially suitable for scenes with high appearance requirements such as commercial buildings and office buildings.
The composite structure of aluminum composite panels makes it better than a single material in terms of impact resistance, weather resistance, and fire resistance, and can adapt to the needs of different environments. The polyethylene core material in the middle has a buffering effect, and the outer aluminum alloy plate provides hardness support. The combination of the two makes the plate highly impact-resistant and less prone to dents and scratches from daily collisions or friction. It is suitable for use in public places or exterior walls with dense traffic. NEWCOBOND® ACP has high construction efficiency. The plates have uniform specifications (commonly 1220mm × 2440mm), and are easy to cut and splice. They can be installed using various installation methods such as dry hanging and pasting. The construction period is more than 30% shorter than that of stone, which can speed up the overall progress of the project and reduce labor costs. We welcome OEM and customization request; regardless of the standard or color you like, NEWCOBOND® will give an appropriate solution for your projects. They are extremely lightweight and study, making them ideal for environments where safety is a concern.
NEWCOBOND used recyclable PE materials that imported from Japan and Korea, composite them with pure AA1100 aluminum, it’s totally non-toxic and friendly to environment.
NEWCOBOND ACP has good strength and flexibility, it’s easy to transform, cut, fold,drill, curve and install them.
Surface treatment with high-grade ultraviolet-resistant polyester paint (ECCA) request, guarantee 8-10 years; if use the KYNAR 500 PVDF paint, guaranteed 15-20 years.
NEWCOBOND can supply OEM service, we can customize size and colors for clients. All RAL colors and PANTONE colors are available
| Aluminum Alloy | AA1100 |
| Aluminum Skin | 0.18-0.50mm |
| Panel Length | 2440mm 3050mm 4050mm 5000mm |
| Panel Width | 1220mm 1250mm 1500mm |
| Panel Thickness | 4mm 5mm 6mm |
| Surface treatment | PE / PVDF |
| Colors | All Pantone & Ral Standard Colors |
| Customization of size and color | Available |
| Item | Standard | Result |
| Coating Thickness | PE≥16um | 30um |
| Surface pencil hardness | ≥HB | ≥16H |
| Coating Flexibility | ≥3T | 3T |
| Color Difference | ∆E≤2.0 | ∆E<1.6 |
| Impact Resistance | 20Kg.cm impact -paint no split for panel | No Split |
| Abrasion Resistance | ≥5L/um | 5L/um |
| Chemical Resistance | 2%HCI or 2%NaOH test in 24hours-No Change | No Change |
| Coating Adhesion | ≥1grade for 10*10mm2 gridding test | 1grade |
| Peeling Strength | Average ≥5N/mm of 180oC peel off for panel with 0.21mm alu.skin | 9N/mm |
| Bending Strength | ≥100Mpa | 130Mpa |
| Bending Elastic Modulus | ≥2.0*104MPa | 2.0*104MPa |
| Coefficient of Linear Thermal Expansion | 100℃ temperature difference | 2.4mm/m |
| Temperature Resistance | -40℃ to +80℃ temperature without change of color difference and paint peel off,peeling strength average dropped≤10% | Change of glossy only.No paint peel off |
| Hydrochloric Acid Resistance | No change | No change |
| Nitric Acid Resistance | No Abnormity ΔE≤5 | ΔE4.5 |
| Oil Resistance | No change | No change |
| Solvent Resistance | No base exposed | No base exposed |
