NEWCOBOND® A2 Fireproof Aluminum Composite Panel From China Factory

Short Description:

Aluminum composite panels with the NEWCOBOND® A2 fireproof coating are made specifically for projects that need to be fireproof. They have an A2 fire rating and are composed of fireproof core materials. Because of their exceptional fire resistance, they are now one of the most extensively utilized fireproof building materials worldwide, being used in a wide range of projects, including hotels, offices, schools, hospitals, and shopping centers. Since its founding in 2008, NEWCOBOND® fireproof ACP has exported to over 20 countries and earned a stellar name for its exceptional fireproof performance and cost-effectiveness. The most common thickness is 4*0.3mm, 4*0.4mm, and 4*0.5mm; however, the size can be altered to meet the needs of the project.


Product Detail

Product Tags

In various public places (airports, stations, hospitals, shopping malls), high-rise buildings and strictly regulated projects, its excellent fire resistance performance is the preferred reason, which can significantly enhance the overall fire safety level of buildings. The surface of the aluminum composite panel is smooth and dense, not easy to get dirty, and can be cleaned as new when washed by rain, and long-term use does not require frequent cleaning and maintenance, saving a lot of later costs. Fireproof aluminum composite panels successfully integrate decoration, functionality, and safety, making them standout representatives of modern building materials. It is not only a decorative material, but also a functional component that raises the standard of building safety. If required, we can provide fire proof to ensure safety.

STRUCTURE

p3

ADVANTAGES

p1

ENVIRONMENTAL FRIENDLY

NEWCOBOND used recyclable PE materials that imported from Japan and Korea, composite them with pure AA1100 aluminum, it’s totally non-toxic and friendly to environment.

p2

EASY PROCESSING

NEWCOBOND ACP has good strength and flexibility, it’s easy to transform, cut, fold,drill, curve and install them.

p3

WEATHER-RESISTANT

Surface treatment with high-grade ultraviolet-resistant polyester paint (ECCA) request, guarantee 8-10 years; if use the KYNAR 500 PVDF paint, guaranteed 15-20 years.

p4

OEM SERVICE

NEWCOBOND can supply OEM service, we can customize size and colors for clients. All RAL colors and PANTONE colors are available

DATA

Aluminum Alloy AA1100
Aluminum Skin 0.18-0.50mm
Panel Length 2440mm 3050mm 4050mm 5000mm
Panel Width 1220mm 1250mm 1500mm
Panel Thickness 4mm 5mm 6mm
Surface Treatment PE / PVDF
Core Material A2 Fireproof
Customization of size and color Available
Item Standard Result
Coating Thickness PE≥16um 30um
Surface pencil hardness ≥HB ≥16H
Coating Flexibility ≥3T 3T
Color Difference ∆E≤2.0 ∆E<1.6
Impact Resistance 20Kg.cm impact -paint no split for panel No Split
Abrasion Resistance ≥5L/um 5L/um
Chemical Resistance 2%HCI or 2%NaOH test in 24hours-No Change No Change
Coating Adhesion ≥1grade for 10*10mm2 gridding test 1grade
Peeling Strength Average ≥5N/mm of 180oC peel off for panel with 0.21mm alu.skin 9N/mm
Bending Strength ≥100Mpa 130Mpa
Bending Elastic Modulus ≥2.0*104MPa 2.0*104MPa
Coefficient of Linear Thermal Expansion 100℃ temperature difference 2.4mm/m
Temperature Resistance -40℃ to +80℃ temperature without change of color difference and paint peel off,peeling strength average dropped≤10% Change of glossy only.No paint peel off
Hydrochloric Acid Resistance No change No change
Nitric Acid Resistance No Abnormity ΔE≤5 ΔE4.5
Oil Resistance No change No change
Solvent Resistance No base exposed No base exposed
