NEWCOBOND® High Glossy Colored ACP Best Quality

Short Description:

Because of its exceptional blend of practicality, aesthetic appeal, and functional performance, NEWCOBOND® high glossy aluminum composite panels (ACP) have become a popular option in interior and architectural design. Their most notable benefit is their exceptional aesthetic impact; whether applied to furniture surfaces, interior wall cladding, shop storefronts, or commercial facades, the high-gloss surface produces a smooth, reflecting finish that improves the overall appearance of any area. High-gloss ACP, in contrast to matte or low-sheen materials, reflect light to give the impression of brightness and space, which makes them perfect for areas that want a contemporary, opulent, or striking feel. They give designers a great deal of freedom to complement a variety of style concepts, from bold, upscale interiors to modern minimalism, because they come in a wide range of vivid solid colors and even metallic finishes.


Product Detail

Product Tags

Their exceptional flatness and color retention make them suitable for a variety of applications, including building facades, exterior cladding walls, and outside shop and mall decorating. NEWCOBOND® wall cladding panels have a 20-year color guarantee and exceptional weather resistance thanks to their premium PVDF coating. We accept OEM and customization requirements; no matter what standard or color you desire, NEWCOBOND®  will provide a satisfactory solution for your projects.

STRUCTURE

p3

ADVANTAGES

p1

ENVIRONMENTAL FRIENDLY

NEWCOBOND used recyclable PE materials that imported from Japan and Korea, composite them with pure AA1100 aluminum, it’s totally non-toxic and friendly to environment.

p2

EASY PROCESSING

NEWCOBOND ACP has good strength and flexibility, it’s easy to transform, cut, fold,drill, curve and install them.

p3

WEATHER-RESISTANT

Surface treatment with high-grade ultraviolet-resistant polyester paint (ECCA) request, guarantee 8-10 years; if use the KYNAR 500 PVDF paint, guaranteed 15-20 years.

p4

OEM SERVICE

NEWCOBOND can supply OEM service, we can customize size and colors for clients. All RAL colors and PANTONE colors are available

DATA

Aluminum Alloy AA1100
Aluminum Skin 0.18-0.50mm
Panel Length 2440mm 3050mm 4050mm 5000mm
Panel Width 1220mm 1250mm 1500mm
Panel Thickness 4mm 5mm 6mm
Surface treatment PE / PVDF
Colors All Pantone & Ral Standard Colors
Customization of size and color Available
Item Standard Result
Coating Thickness PE≥16um 30um
Surface pencil hardness ≥HB ≥16H
Coating Flexibility ≥3T 3T
Color Difference ∆E≤2.0 ∆E＜1.6
Impact Resistance 20Kg.cm impact -paint no split for panel No Split
Abrasion Resistance ≥5L/um 5L/um
Chemical Resistance 2%HCI or 2%NaOH test in 24hours-No Change No Change
Coating Adhesion ≥1grade for 10*10mm2 gridding test 1grade
Peeling Strength Average ≥5N/mm of 180oC peel off for panel with 0.21mm alu.skin 9N/mm
Bending Strength ≥100Mpa 130Mpa
Bending Elastic Modulus ≥2.0*104MPa 2.0*104MPa
Coefficient of Linear Thermal Expansion 100℃ temperature difference 2.4mm/m
Temperature Resistance -40℃ to +80℃ temperature without change of color difference and paint peel off,peeling strength average dropped≤10% Change of glossy only.No paint peel off
Hydrochloric Acid Resistance No change No change
Nitric Acid Resistance No Abnormity ΔE≤5 ΔE4.5
Oil Resistance No change No change
Solvent Resistance No base exposed No base exposed
